Customized Three-Axis Servo Robotic Arms: A Procurement Guide from Requirements to Delivery

Customized Three-Axis Servo Robotic Arms: A Procurement Guide from Requirements to Delivery

For injection molding enterprises worldwide, choosing a customized 3-axis servo robotic armthat fits their production needs is crucial to improving efficiency, reducing labor costs, and achieving intelligent transformation. However, many buyers face challenges such as mismatched specifications, delayed delivery, and unclear after-sales support during the customization process. As a leading manufacturer of automated intelligent equipment, ZHIYI (Zhejiang Zhiyi Intelligent Robot Co., Ltd.) provides a one-stop customization service from demand communication to delivery and maintenance. This guide will detail the full procurement process of ZHIYI customized 3-axis servo robotic arms, helping you avoid risks and make efficient purchasing decisions.

1. Clarify Your Production Needs: The Foundation of Customization

Before starting the customization, clarifying your core production requirements is the first step to ensure The Robotic Arm matches your injection molding line. ZHIYI’s engineering team recommends focusing on the following key parameters—these details will directly determine the design direction of the customized 3-axis servo robotic arm.

1.1 Confirm Injection Molding Machine Tonnage & Matching Requirements
The tonnage of your injection molding machine is the primary factor in selecting a robotic arm. Different tonnages correspond to different load capacities and stroke ranges of the robotic arm:
For 80~320T injection molding machines: If you mainly produce small to medium-sized products (such as electronic casings, small plastic parts), ZHIYI’s WKG-1000 3-axis single-arm single-section robotic arm (with a standard load of 3~8kg) is a suitable choice, which can realize efficient product removal.

For 350~1300T injection molding machines: If you need to handle medium-sized molds or products (such as auto parts, large plastic containers), ZHIYI’s 3-axis servo robotic arm series (with a load of 15~50kg) can meet the demand, and its high-rigidity aluminum alloy structure ensures stable operation.

For 800~4000T large injection molding machines: For heavy-duty scenarios such as complex mold picking and large product transfer, ZHIYI Bull Head 3-Axis Servo Robotic Arm (maximum load 50kg) is optimized for large strokes and high load capacity, perfectly adapting to high-tonnage equipment.

#Injection molding machine tonnage matching customized 3-axis servo robotic arm

1.2 Define Load Capacity & Application Scenarios
The load capacity of the robotic arm must match the weight of your product (including fixtures). At the same time, clarify the specific application scenarios to ensure the robotic arm has corresponding functional configurations:

Basic product removal: If you only need to complete simple tasks such as taking out finished products from the mold and placing them on the conveyor belt, ZHIYI’s standard 3-axis servo robotic arm (equipped with a suction cup/fixed claw fixture) can meet the needs.

In-mold insert & water gap cutting: For scenarios requiring in-mold embedding of metal parts or post-mold water gap cutting, ZHIYI can customize a pneumatic auxiliary arm or add a servo cutting module to the robotic arm to realize integrated operations.

High-speed thin-wall product production: If you produce thin-wall products such as milk tea cups and lunch boxes (requiring fast cycle times), ZHIYI’s high-speed 3-axis servo robotic arm (empty cycle time as low as 3.5 seconds) can improve production efficiency by more than 20%.

#In-mold insert customized 3-axis servo robotic arm solution

1.3 Provide Workshop Layout & Space Constraints
To avoid installation interference, you need to provide ZHIYI with the workshop layout diagram, including:

The height of the workshop (determines the stroke of the robotic arm’s Z-axis, i.e., lifting direction).
The distance between the injection molding machine and surrounding equipment (ensures the robotic arm’s X-axis (lateral movement) and Y-axis (front-back movement) have sufficient space).

The height of the safety door and the position of the mold (avoids collision between the robotic arm and the mold during operation).

2. Select a Reliable Customization Supplier: Verify ZHIYI’s Core

Advantages
Choosing a supplier with strong technical strength and rich experience is the key to the success of customization. ZHIYI has won the trust of global customers (such as HAERS, CAYI, and FEIJIAN) with its professional capabilities. When evaluating suppliers, you can focus on the following aspects:

2.1 International Quality Certification & Technical Patents
Quality is the cornerstone of customized equipment. ZHIYI’s 3-axis servo robotic arms have passed ISO9001 quality management system certification and EU CE certification, and all products undergo rigorous load testing, fatigue testing, and safety performance testing before leaving the factory to ensure compliance with international standards.
In terms of technology, ZHIYI has 13 utility patents (covering core technologies such as servo drive control and high-rigidity arm design) and has been rated as a “national high-tech enterprise” since 2021, ensuring the advancement and reliability of customized solutions.

#ZHIYI ISO9001 certified 3-axis servo robotic arm

2.2 Rich Customization Cases & Industry Experience
Since its establishment in 2017, ZHIYI has completed more than 500 customization projects covering industries such as daily chemical packaging, auto parts, and medical devices. For example:
For a Russian injection molding enterprise, ZHIYI customized a 3-axis servo robotic arm with a low-height design (adapted to the workshop with a height of only 3.5 meters) to realize the automatic removal of T-shaped pipe fittings.

For a domestic food packaging enterprise, it customized a high-speed 3-axis robotic arm matching 16-cavity wet tissue cover molds, reducing the production cycle from 8 seconds to 5.2 seconds.
These cases prove ZHIYI’s ability to adapt to diverse needs. You can ask the supplier to provide cases in the same industry for reference.

#Reliable customized 3-axis servo robotic arm supplier

2.3 Flexible Customization Capabilities & Fast Response
ZHIYI’s customization service supports “one machine, one solution”:
Mechanical structure customization: According to your needs, adjust the arm length, stroke, and fixture type (such as replacing suction cups with clamping jaws for irregular products).

Control system optimization: Integrate the robotic arm with your MES system (if needed) to realize data interconnection and remote monitoring.

Fast quotation & scheme confirmation: ZHIYI’s engineering team will provide a preliminary customization scheme and quotation within 48 hours after receiving your demand information, and adjust it according to your feedback in a timely manner.

3. Communicate & Confirm the Customization Scheme: Avoid Post-Delivery Deviations

The communication stage is the key to reducing disputes. ZHIYI adopts a “three-step confirmation mechanism” to ensure that the scheme fully meets your expectations:

3.1 On-Site Survey (Optional for Global Customers)
For customers with complex needs (such as multi-machine linkage or special workshop environments), ZHIYI can arrange engineers to conduct on-site surveys (or online 3D scanning of the workshop) to confirm:
The actual size and operation status of the injection molding machine.
The weight, shape, and material of the product (to design the fixture).
The coordination requirements with other equipment (such as conveyors, testing machines).

3.2 Scheme Demonstration & Simulation Testing
After confirming the requirements, ZHIYI will provide a detailed customization scheme, including:
2D/3D drawings of the robotic arm (showing the structure, dimensions, and installation position).
Parameter list (load capacity, stroke, cycle time, repeat positioning accuracy ±0.1~±0.2mm).
Configuration list (brand of servo motor, type of linear guide rail, etc.).
If needed, ZHIYI can conduct simulation tests in its modern factory (located in Jinhua, Zhejiang) and send the test video to you, verifying the feasibility of the scheme in advance.

#Customized 3-axis servo robotic arm scheme communication points

3.3 Sign a Detailed Contract
The contract will clearly stipulate:
Customization requirements (parameters, functions, delivery standards).
Delivery cycle (ZHIYI’s annual production capacity is 2500 units, and the standard customization cycle is 2~4 weeks; urgent orders can be prioritized).
Payment terms and after-sales commitments.

4. Production, Delivery & Installation: Achieve Rapid Production

4.1 Strict Production Quality Control
ZHIYI’s production workshop adopts an intelligent management system to monitor the production process in real time:
Core component procurement: Use well-known brand components (such as imported AC servo motors, high-rigidity linear guide rails) to ensure the service life of the robotic arm (average service life ≥5 years).
Semi-finished product inspection: Conduct load testing and movement accuracy testing on the robotic arm’s arm, drive system, and other components to eliminate defective products.

4.2 Efficient Global Delivery
ZHIYI cooperates with international logistics companies to provide door-to-door delivery services for global customers. The delivery package includes:
Customized 3-axis servo robotic arm (main machine + fixtures).
Installation tools and manuals (in Chinese/English).
Spare parts kit (common wearing parts such as suction cups, screws).

4.3 Professional Installation & Operation Training
After the robotic arm arrives, ZHIYI’s after-sales team will:
Provide online or on-site installation guidance (on-site service is available for key customers).
Train your operators (including parameter setting, daily maintenance, and fault handling).
Conduct joint debugging with your injection molding machine to ensure the robotic arm runs stably.

#ZHIYI customized 3-axis servo robotic arm on-site installation service

5. After-Sales Support & Maintenance: Ensure Long-Term Stable Operation

The service after delivery is equally important. ZHIYI provides “full-life cycle support” for customized 3-axis servo robotic arms:

5.1 24/7 Technical Support
Global customers can contact ZHIYI’s after-sales team through:
Hotline: +86 0579-83987825 (available 24 hours).
Online platform: Submit maintenance requests through the official website (https://www.zhiyirobotics.com/) and get a response within 2 hours.

5.2 Warranty & Maintenance Services
Warranty period: Provide a 12~24-month warranty for the main machine (depending on the customization scheme), during which free replacement of faulty components is available.
Regular maintenance reminder: ZHIYI will send maintenance reminders (such as lubricating the linear guide rail, checking the servo system) according to the usage time of the robotic arm.
Lifetime technical upgrade: Provide discounted technical upgrade services (such as adding a vision detection module) to adapt to your future production needs.

#ZHIYI customized 3-axis servo robotic arm after-sales support
